SKYBIT™ FC-H7
Sale priceRs. 7,200.00Regular price
Rs. 12,000.00
The SKYBIT™ FC-H7 is designed for FPV and micro drone builders, offering powerful performance with seamless integration and full ArduPilot firmware support. Its compact yet robust design makes it ideal for professional drone developers as well as enthusiasts.
The SKYBIT™ FC-H7 combines performance, reliability, and user-friendly integration, making it the perfect choice for builders who demand precision and efficiency in every flight.
In stock, ready to ship
Couldn't load pickup availability
Pickup available at Skybit™, Pimpri
Usually ready in 24 hoursPairs well with
Made in India
12 Months Warranty
In stock! Ships within 1-2 business days.
SKYBIT™ FC-H7
Sale priceRs. 7,200.00Regular price
Rs. 12,000.00
Product details
Specifications
- MCU : STM32H743 32-bit processor running at 480 MHz
- Mechanical Reinforcement : Professional underfill epoxy for mechanical reinforcement
- UARTs : 6
- PWM Outputs : 9× PWM outputs (8 motor outputs + 1 LED)
- ESC Ports : 2× JST-SH 1.0 8-pin ESC ports (4-in-1 ESCs, x8/Octocopter compatible)
- VTX Port : 1× VTX port — JST-SH 1.0 4-pin (for HD systems like Caddx Vista / Air Unit / other VTX)
- Battery Input Voltage : 3S – 8S
- BEC : BEC 5V 2A (continuous), 9V 3A (continuous)
- USB : Type - C
- Mounting : 30.5 × 30.5 mm with Ø4 mm holes using Ø3 mm grommets
- Dimensions (mm) : 39 × 39 mm
- Weight (gm) : 8
Warranty
SKYBIT™ drone components come with a 12-month limited warranty from the date of purchase, covering defects in materials under normal use as specified in User manual of the products. If your product experiences a manufacturing defect, we'll repair or replace it at no charge . To make a claim, simply contact our support team at techsupport@skybit.co.in with your proof of purchase and product details. Please note that the warranty doesn't cover damage from misuse, unauthorized modifications, accidents, or normal wear and tear. All SKYBIT™ products are designed and manufactured in India with rigorous quality standards, and we stand behind our craftsmanship with local support you can trust.
Other Information
Country Of Origin : India
Brand : Skybit™
Manufactured By : Griffyn AI Labs Pvt. Ltd.
Address : Unit No. 4, Shewale Center – B, Survey No. CTS4691, MIDC, Pimpri Colony, Pimpri Chinchwad, Maharashtra – 411019
Mobile Number : +91-9028654684
Mail : techsupport@skybit.co.in
For any query or complaint, you can call or email the above details.
FAQs
What processor does the Skybit™ FC H7 use?
It features the STM32H743 32-bit processor running at 480 MHz, delivering high processing power for advanced flight control and telemetry tasks.
Which IMUs and sensors are onboard the Skybit™ FC-H7?
It uses the BMI270 IMU for accurate motion sensing. The barometer sensor is BMP581 for altitude measurements.
What is the battery input voltage range?
Supports 3S to 8S LiPo batteries, corresponding to approximately 7V to 42V, allowing use with a wide range of power setups.
How many UART ports are available and what are their functions?
Six dedicated UART ports (UART1,2,3,4,6,7) with built-in inversion for compatible peripherals. UART2 is reserved for Bluetooth telemetry by default. Bluetooth is not supported for Ardupilot. It is only supported for Betaflight firmware. Currently Betaflight firmware is in Development.
What ESC configurations does the Skybit™ FC-H7 support?
Dual JST-SH 8-pin ports allow plug-and play connection of 4in1 ESCs supporting up to octocopter (8 motors) configurations. This simplifies wiring and assembly.
Is there onboard video system support?
Yes, includes a JST-SH 4-pin port dedicated for HD video systems like 9V/3A output to power video transmitters. It also supports Analog/ Digital VTX systems.
What data logging capabilities does it offer?
Equipped with 128MB flash memory for extensive Blackbox logging for flight data analysis and troubleshooting.
What flight control firmware platforms are compatible?
Currently Supports Ardupilot firmware only.
Physical dimensions and additional features?
30.5 × 30.5 mm with Ø4 mm holes using Ø3 mm grommets, weighs around 8 grams and dimension 39 × 39 mm.
Is FC-H7 compatible for surveillance drones?
Yes, ideal for multirotor drones such as quadcopters, hexacopters, and octocopters, as well as fixed-wing UAVs and hybrid VTOL platforms. FPV racing drones that benefit from its low-latency control and integrated Bluetooth (Betaflight) tuning.
Is it like Cube orange flight control board?
No, It's not.
